Specifications
BMW 315/1 Sport
Date of manufacture
1934 -1936
Bodywork type(s)
2 seater sports (Some Frazer Nash-BMWs with English coachwork)
Engine
Type Inline 6 cylinder
Capacity 1490cc
Bore x stroke 58mm x 94mm
Power 40bhp @ 4300rpm
Compression 6.8:1
Carburettors 3, Solex 26 mm sidedraught
Valve design Overhead, 2 per cylinder
Valve gear Camshaft in block. Push rods, Rockers, tappets and springs
Electrics 6 volt
Transmission
Clutch Dry single disc. Fichtel & Sachs, K 10, 180 mm diameter.
Gearbox ratios
Hurth
1st 4.08:1
2nd 2.35:1
3rd 1.52:1
4th 1.00:1
Axle ratio 4.38:1
Synchromesh 3rd and 4th
Chassis
Frame Lightweight “A”-frame with two longitudinal tubular members,
with varying diameter from 90 mm to 60 mm
dependant on load , and three
rectangular cross members
Suspension Front: Transverse leaf spring with lower wishbones
and integral single acting shock absorbers.
Rear: Longitudinal leaf springs with rigid axle
and lever arm double acting shock absorbers.
Foot operated one shot central oil lubrication system
Steering Rack and pinion
Brakes Four wheel Bendix cable
Handbrake, cable on rear wheels
Dimensions
Wheelbase 2400mm
Track front/rear 1153/1220mm
Length/width 3900mm x 1440mm
Tyres 5.25 x 16
General
Fuel capacity 42 litres
Max speed 75 mph
Number produced 230 (15 rhd)
